General features
Moreless| Part no. | 61 0795 098 00 |
| Version | Pin contact |
| Cross-sectional area | 0.35-0.50 mm² |
| Crimp dimensions (guide value) | 0.35 mm²: 0.93-1.1 mm - 0.50 mm²: 0.95-1.12 mm |
| Crimp pullout force | 0.35 mm²: 53 N - 0.50 mm²: 73 N |
| Weight (g) | 14.03 |
| Customs tariff number | 74093900 |
| Country of Origin | DE |
Material
Moreless| Contact material | CuSn (bronze) |
| Contact plating | Au (gold) |
| REACH SVHC |
None (No pollutants) |
| SCIP number | SCIP-number not available |
Classifications
Moreless| eCl@ss 11.1 | 27-46-04-03 |
Security notices
- The user must take suitable safety precautions to ensure that the connector cannot be accidentally disconnected.
